10T/H Fire Tube Oil Steam Boiler 37kw Lpg Fired Steam Boiler

Name: 10TH Fire Tube Oil Steam Boiler 37kw Lpg Fired Steam Boiler
Brand: SWET
Price: 1 USD

Brand Name : SWET

Model Number : WNS10-1.25-Q(Y)

Certification : ISO9001

Place of Origin : Henan China

MOQ : 1 Set/Sets

Price : Negotiation

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram，Cash or on the basis of mutual agreement

Supply Ability : 1500 Set/Sets Per Year

Delivery Time : Within 30 days after payment

Packaging Details : The boiler in nude package, but covered with water-proof covering, accessories in plywood case or tin case, this can be changed as your requirements

Rated evaporation : 10T

Work pressure : 1.25MPa

Steam temperature : 194℃

Design thermal efficiency : 96.75%

Rated oil consumption : 688kg/h

Power consumption : 37kw

Exhaust temperature : 136.3℃

Contact Now

10t Full Automatic oil gas steam boiler for industrial production

WNS Oil Fired Steam Boiler offered by us are designed and manufactured to deliver optimum functionality in the given environment. Backed by cutting edge features and special designs, these fully automatic systems provide complete ease of operations and maintenance. Package Type, Fully Automatic, three pass & water tube design electric steam boilers.

1. Stainless packing,corrosion prevention

2. Corrugated furnace,Enlarge the heating area

3. Design with reversal chamber in furnace,wet back structure,reduce the boiler surface temperature,reduce heat loss.

4. Two front door,easy for maintenance

5. Equipe with blast-resistant door,make sure the boiler working safely

6. Water-steam seperate equipment,improve steam quality

WNS series of automatic gas (oil) steam energy-saving boiler
Model	Rated evaporation	Work pressure	Steam temperature	Feed water temperature	Air consumption	Test efficiency	Transport dimensions
Unit	t/h	MPa	℃	℃	Nm³/h	%	mm
WNS20-2.5-Q(Y)	20	2.5	226	105	1407.5	97.62	8660x3520x4831
WNS20-1.25(1.6)-Q(Y)	20	1.25/1.6	194/204	105	1459	97.51	8870x3550x3750
WNS15-1.0(1.25)(1.6)-Q(Y)	15	1.0/1.25/1.6	184/194/204	105	1126	97.2	7450x3520x4090
WNS10-1.25(1.6)-Q(Y)	10	1.25/1.6	194/204	105	837.25	96.75	6370x2812x3514
WNS8-1.25(1.6)-Q(Y)	8	1.25/1.6	194/204	105	659.25	96.7	6000x2920x3430
WNS6-1.25(1.6)-Q(Y)	6	1.25/1.6	194/204	105	433.51	96.58	5470x2770x3195
