Brand Name : SWET
Model Number : WNS
Certification : ISO9001
Place of Origin : Henan,China
MOQ : 1 set
Price : Negotiation
Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability : 1200 set/ year
Delivery Time : 25-30 works day
Packaging Details : Wood care plus tarpaulin packaging
Structure : Fire Tube
Design fuel : natural gas,diesel,heavy oil
Thermal efficiency : 96.57%
Dimension : 5950*2556*3120 (mm)
Usage : Industrial
Weight : 3~50ton
Product Description
Technical Parameters
WNS series automatic gas (oil) steam energy saving boiler product selection form | Model | Unit | WNS6-1.25(1.6)-Q(Y) |
Rated capacity | t/h | 6 | |
Working pressure | Mpa | 1.25/1.6 | |
Steam temperature | ℃ | 194/204 | |
Feed temperature | ℃ | 105 | |
Testing efficiency | % | 96.58 | |
Diesel consumption | Kg/h | 379.32 | |
Gas consumption | Nm³/h | 433.51 | |
Outline dimension | mm(L*W*H) | 5470*2770*3195 |
![]() |
Low Pressure Industrial Steam Boiler 5.6 MW 12 MW Gas Oil Hot Water Boiler For Food Industry Images |
